What is the Cambium PMP 450v?

The PMP 450v is Cambium's latest-generation 5 GHz PMP access point. It delivers improved SNR, more capacity per sector, and higher subscriber density than 450i and 450m, with full backward compatibility to existing 450 subscriber modules.

Can the PMP 450v replace a 450i or 450m in place?

Yes. The 450v is a drop-in mount and form-factor replacement for most existing PMP 450 sectors. Existing SMs, backhaul, and cnMaestro configuration carry over — most WISPs cut over in a single maintenance window.

Is the PMP 450v BEAD-eligible?

Yes. PMP 450v deployments meet BEAD 2.0 technical criteria for reliable broadband. Pair with cnHeat RF modeling and LINKPlanner outputs to satisfy BEAD cost-per-location and performance documentation.

What subscriber modules work with PMP 450v?

All current Cambium PMP 450 subscriber modules are supported, including the 450b 5 GHz SM (integrated and high-gain), 450 MicroPoP SMs, and legacy 450 SMs.

Cambium Networks PMP 450v Fixed Wireless Access Point

Fixed wireless broadband distribution to rural, suburban, and underserved communities at scale.

Talk to a Pro

PMP 450v

Specs: Deliver high performance to business and residential

Operates from 5.15 GHz to 7.125 GHz
Backward and forward compatible and future proof
4x4 MIMO access point

Better pricing available. Our experts can help you secure the lowest rate on this model. Talk to an expert →

Request a Quote

Fast shipping — same-day processing before 4:15 pm PST
Authorized Reseller — Serving customers 20+ years
Call for Bulk Pricing

Sorry, this product is no longer available, please contact us for a replacement.

Click here to jump to more pricing!

Product Overview

Cambium Networks PMP 450v Fixed Wireless Access Point

Broadband service providers seeking to increase capacity and service levels can use the PMP 450v fixed wireless AP and SM to easily upgrade an existing PMP 450 network by leveraging the higher capacity of the 6 GHz spectrum.

PMP 450

Product Highlights

Backward and Forward Compatibility

Leverage existing platform investment, and migrate gracefully to the

increased flexibility.

carriers) across two independent carriers of different bandwidths* GHz can utilize larger channels).

Dual Sector Mode

Operate carriers independently (i.e., one GHz and one GHz) with

Carrier Aggregation

Achieve flexibility in spectrum usage using three channels (component (e.g., when GHz may be congested requiring smaller channels, and

Ideal Applications

Fixed wireless broadband distribution to rural, suburban, and underserved communities at scale. ISP last-mile buildouts requiring scalable point-to-multipoint architecture with high spectral efficiency.

Product Images

4 photos

Technical Details

Hardware Specifications

Comprehensive technical data for the PMP 450v to ensure compatibility with your deployment.

Interface

CambiumNetworks proprietary

Physical Layer 2x2 MIMOOFDM

Ethernet Interface 100/1000BaseT,full duplex, rate auto negotiated (802.3 compliant)

Protocols Used IPv4, IPv6,UDP, TCP/IP, ICMP, Telnet, SNMP, HTTP, FTP

IPv4/IPv6(dual stack), HTTP, HTTPS, Telnet, FTP, SNMPv2c and v3, Cambium Networks cnMaestro™

Management

VLAN 802.1ad(DVLAN Q-inQ), 802.1Q with 802.1p priority, dynamic port VID MCS Signal to Noise Required (SNR, in dB)

2xQPSK 10

3x8QAM 13

4x16QAM 17

5x32QAM 21

6x64QAM 24

7x128QAM 28

8x256QAM 32

Up to 40mi (64 km)

3–5 ms,typical

Yes, viaembedded GPS, or Cambium Sync

DiffserveQoS

Antenna

Integrated Sector 17 dBi ±1dBi integrated 90°/120° sector

3 dB Beamwidth – ±45° (±60°@ 6 dB roll-off)

5° withnull fill

Dual linear,H+V PMP 450v 4x4 Fixed Wireless Access Point

Maximum Transmit +28 dBm(MIMO, combined H+V) for 5 GHz, +20 dBm for 6 GHz (may be limited by regulations)

+45 dBmcombined output in 5 GHz, +37 dBm in 6 GHz (may be limited by regulations)

ATPC (AutomaticTransmit Power Control) at system level, all subscribers implement ATPC

Antenna

N/A – Integratedsector antenna

Surge Suppression EN 61000-4-5:10x700 μs, 6 kV, EN 61000-4-2: ESD 8 kV contact / 15 kV air

Recommendedexternal surge suppressor: Cambium Model # C000000L033A

-40°C to+60°C (-40°F to +140°F), 0%–100% condensing

6.3 kg(13.9 lb), 9.1 kg (20 lb) with bracket

200 kph(124 mph)

NEMATS2 Section 2.1.9 and Section 2.2.3

NEMATS2 Section 2.1.10 and Section 2.2.4

NEMA250-2003 Section 5.6

673 x 222x 134 mm (26.5 x 8.75 x 5.3 in)

45W typical,55W max, using aux port PoE for another device will increase power draw

48-59 VDC,802.3bt type 4 class 8 (also accepting passive PoE)

Security

Encryption FIPS-197128 bit AES, 256-bit AES (requires optional license)

Certifications

CE TBDPMP 450v 4x4 Fixed Wireless Access Point

ABOUT CAMBIUM NETWORKS

Cambium Networks enablesservice providers, enterprises, industrial organizations, and governments to deliver exceptional digital

experiences and device connectivitywith compelling economics. Our ONE Network platform simplifies management of Cambium

Networks’ wired and wirelessbroadband and network edge technologies. Our customers can focus more resources on managing

their business rather than thenetwork. We make connectivity that just works.

Downloads

Documentation & Resources

Download datasheets and technical documentation for the PMP 450v.

Data Sheet

Download PDF →
