PTP 850EX
- Specs: E-Band / V-Band Licensed Microwave PTP with 1024 QAM and Adaptive Coding & Modulation
- Capable of 1024 QAM with ACM
- Supports 71–76 GHz, 81–86 GHz
- Supports 1+0, 2+0*, 1+1 HSB*
- Includes built-in frequency scanner
Better pricing available. Our experts can help you secure the lowest rate on this model. Talk to an expert →
Request a Quote- Fast shipping — same-day processing before 4:15 pm PST
- Authorized Reseller — Serving customers 20+ years
- Call for Bulk Pricing
Sorry, this product is no longer available, please contact us for a replacement.
Click here to jump to more pricing!
Product Overview
Cambium Networks PTP 850EX
Capable of 1024 QAM with ACM, Supports 71-76 GHz, 81-86 GHz
PTP
Product Highlights
Features
BPSK to QAM with hitless ACMB (Adaptive
MTU 9,612 bytes
Quality of Service Multiple classification criteria (VLAN ID, p-bits, IPv4 CoS queues per port Deep buffering (configurable up to Mbit per queue)
VLAN add/remove/translate
Network Protocols MSTP, ERP (ITU-T G.8032) Y.1731 Ethernet OAM Y.1731 Ethernet bandwidth notification (ETH-BN)
Ideal Applications
High-capacity wireless backhaul replacing leased lines between towers, buildings, and campuses. Mobile network backhaul and enterprise campus connectivity requiring carrier-grade link reliability.
Product Images
2 photos
Technical Details
Hardware Specifications
Comprehensive technical data for the PTP 850EX to ensure compatibility with your deployment.
Protocols REST
SDN Support:NETCONF/YANG
Enhanced Ethernet equipmentclock (eEEC) Specification (G.8262.1)
PTP telecom boundary clock(T-BC) and Time Save Clock (T-TSC) specification (G.8273.2)
PTP telecom transparent clock(T-TC) specification (G.8273.3)
Enhanced SyncE network limits(G.8261, clause 9.2.1)
Enhanced PTP network limits(G.8271.1)
Ethernet synchronization messagingchannel (ESMC) (G.8264, clause 11)
PTP telecom profile for time(full timing support) (G.8275.1)
Precision time protocol (version2, IEEE1588-2008)
Security
Secured protocols (HTTPS, SNMPV3,SSH, SFTP)
TACACS+ authentication andauthorization (session based)
Standard
MEF CarrierEthernet 2.0
Supported Ethernet 10/100/1000base-T/X(IEEE 802.3)
Standards:
Optical10Gbase-LR (IEEE 802.3ae)
EthernetVLANs (IEEE 802.3ac)
VirtualLAN (VLAN, IEEE 802.1Q)
Class ofservice (IEEE 802.1p)
Providerbridges (Q-in-Q – IEEE 802.1ad)
Link aggregation(IEEE 802.1ax)
Auto MDI/MDIXfor 1000baseT
RFC 1349:IPv4 TOS
RFC 2474:IPv4 DSCP
RFC 2460:IPv6 Traffic Classes PTP 850EX Millimeter Wave Radio
Standards Compliance
Radio Spectral EN 302217-2
Compliance EMC: EN301 489-1, EN 301 489-4, Class A(Europe)
FCC 47CFR, part 15, subpart B, class A(US) ICES-003, Class A(Canada) TEC/SD/DD/EMC-221/05
TEC/SD/DD/EMC-221/05/OCT-16,Class A (India)
Surge EN61000-4-5,Class 4 (for PWR and ETH1/PoE ports)
Safety: EN 60950-1,EN 62368-1, IEC 60950-1, IEC 62368-1, UL60950-1, UL 62368-1, CAN/CSA C22.2 NO 60950-1,
CAN/CSAC22.2 NO 62368-1, EN60950-22, IEC 60950-22, UL 60950-22,
CAN/CSAC22.2 NO 60950-22
ETSI EN300 019-1-1 Class 1.2
ETSI EN300 019-1-2 Class 2
Transportation
Dimensions: Direct 228 mmx 233 mm x 76 mm, 2.77 kg
Mount (H x W x D) 8.9 in x9.5 in x 2.95 in, 4.4 lb
Specifications -40°C to+55° ( -40°F to +131°F)
Standard Input -48 VDC
DC Input Range -40.5 to-60 VDC
Max Power 55W
Default License Keys Includedin Keyed Version
PTP 850EX Act.Key - Capacity10G with ACM Enabled, per Tx Chan, PTP 820/850 Act.Key - 10GE port PTP 850EX Millimeter Wave Radio
Transmit Power (dBm)
Channel Size 250 MHz 500MHz 1000 MHz 2000 MHz
2121 21 21
2121 21 21
2121 21 21
2121 21 21
2020 20 20
1919 19 19
1818 18 18
1717 17 17
1616 16 16
1515 15 –
1515 15 –
1414 – –
Receive Sensitivity (dBm@10E-6)
Channel Size 250 MHz 500MHz 1000 MHz 2000 MHz
-77.2-74.2 -71 -68.9
-74.9-71.6 -68.5 -65.9
-69.8-66.4 -63.3 -60.5
-68.4-65.2 -61.9 -59.1
-64.3-61.2 -58.1 -56.2
-62.5-59.2 -56 -53.4
-59.6-56.3 -53 -49.8
-56.7-53.4 -50.1 –
-53.5-50.3 -47 –
-49.5-47.1 – – PTP 850EX Millimeter Wave Radio
Throughput Sensitivity(Mbps)
Channel Size 250MHz 500 MHz 1000 MHz 2000 MHz
BPSK – ¼ channel 48–5998–121 190–234 330–407
95–117197–243 379–467 660–814
BPSK – full 190–235394–485 758–935 1319–1627
382–471788–972 1517–1871 2640–3256
574–7071183–1459 2276–2807 4108–5067
765–9441578–1946 3036–3744 5478–6756
957–11801973–2433 3795–4680 6848–8446
1148–14162367–2920 4554–5616 8218–10000
1340–16522762–3406 5313–6553 9931–10000
1532–18893157–3893 6073–7489 –
1723–21253552–4380 6832–8425 –
1915–23613946–4867 – –
C800085B007A PTP 850EXRadio, 10Gbps, Lo, TX 71-76GHz, RX 81-86GHz, without License keys
C800085B008A PTP 850EXRadio, 10Gbps, Hi, TX 81-86GHz, RX 71-76GHz, without License keys
C800085B009A PTP 850EXKeyed Radio, with Act Keys, 10Gbps, Lo, TX 71-76GHz, RX 81-86GHz
C800085B010A PTP 850EXKeyed Radio, with Act Keys, 10Gbps, Hi, TX 81-86GHz, RX 71-76GHz
ABOUT CAMBIUM NETWORKS
Cambium Networks enablesservice providers, enterprises, industrial organizations, and governments to deliver exceptional digital
experiences and device connectivitywith compelling economics. Our ONE Network platform simplifies management of Cambium
Networks’ wired and wirelessbroadband and network edge technologies. Our customers can focus more resources on managing
their business rather than thenetwork. We make connectivity that just works.
