Cambium Networks PTP 850GP

High-capacity wireless backhaul replacing leased lines between towers, buildings, and campuses.

Cambium Networks PTP 850GP
Talk to a Pro
Contact Us 855-958-0754 Email Sales
PTP 850GP
  • Specs: Licensed Microwave Radio IDU
  • Compact split mount
  • 1RU with conduction cooling
  • High spectral utilization: QPSK
  • Up to 40G capacity

Better pricing available. Our experts can help you secure the lowest rate on this model. Talk to an expert →

Request a Quote
  • Fast shipping — same-day processing before 4:15 pm PST
  • Authorized Reseller — Serving customers 20+ years
  • Call for Bulk Pricing

Sorry, this product is no longer available, please contact us for a replacement.


Click here to jump to more pricing!

Product Overview

Cambium Networks PTP 850GP

PTP 850GP is a highly-flexible, compact, high-performance indoor unit that delivers multi-Gbps radio capacity.

PTP

Product Highlights

x SFP+ Radio Interfaces

x SFP+ Dual Use Radio or Ethernet Interfaces (1/10G)

RFU-D* High-capacity multicore radio

RFU-D-HP* High-capacity, high-power multicore radio RFU-SX* High-capacity single core radio

Radio Features*

Multi-Carrier Adaptive Bandwidth Control with RFU-SX

Space Diversity with RFU-D/RFU-D-HP

High spectral utilization: QPSK to QAM w/ACM

Ideal Applications

High-capacity wireless backhaul replacing leased lines between towers, buildings, and campuses. Mobile network backhaul and enterprise campus connectivity requiring carrier-grade link reliability.

Product Images

2 photos
Product image 1
Product image 2
Technical Details

Hardware Specifications

Comprehensive technical data for the PTP 850GP to ensure compatibility with your deployment.

Specifications

Ethernet Interfaces 6 xSFP+ (1/10G)
2 xSFP28 (1/10/25G)
2 xSFP+ Dual Use Radio or Ethernet Interfaces (1/10G)
1 xRJ-45 Management/Protection Interface (100M)
Management Interfaces 1 x10/100 Base-T (RJ-45)
Ethernet Features VLANadd/remove, MSTP, ERP (ITU-T G.8032), Y.1731 Ethernet OAM,
Y.1731Ethernet Bandwidth Notification (ETH-BN)
MTU 9600bytes
Quality of Service QoSclassification based on TOS/DSCP, VLAN ID, VLAN P-bits, MAC DA and SA, SA and DA IP Addresses (IPv4
andIPv6)
Networking Capacity 193Gbps
Management Protocols SNMP,REST

SDN Support NETCONFIG/YANG

Syncdistribution over any traffic interface (GE/FE, DS1, OC-3)
Dedicatedin/out synch interface (1.5 MHz)
SyncE(ITU-T G.8261, G.8262)
SSM/ESMCsupport for ring/mesh applications (ITU-T G.8264)
SyncEregenerator mode, providing PRC grade (ITU-T G.811) performance for smart pipe applications
OptimizedTransport for reduced PDV

Standards

MEF CarrierEthernet 2.0 (CE 2.0)

Supported Ethernet

Management:100base-T Provider bridges (QinQ – IEEE 802.1ad)

Standards

Traffic:1000base-X and 10Gbase-LR (IEEE 802.3) Link aggregation (IEEE 802.1AX)
VirtualLAN (VLAN, IEEE 802.1Q) Auto MDI/MDIX for 1000baseT
MACbridges (IEEE801.D) RFC 2474: IPv4 DSCP
Classof service (IEEE 802.1p) RFC 2460: IPv6 Traffic Classes

Radio Encryption AES 256

Secured Protocols HTTPS,SNMPv3, SSH, SFTP
Radiusauthentication and authorization
TACACS+authentication, authorization, and accounting (session-based) PTP 850GP

Standards Compliance

EMC EN 301489-4, EN 301 489-1, FCC 47 CFR, part 15, subpart B, ICES-003, TEC/SD/DD/EMC-221/05/OCT-16, IEC 61000-
4-29, EN61000-4-5 Level 4, Emissions tests (CISPR32 Class B)
EN 62368-1,IEC 62368-1, UL 62368-1, CAN/CSA-C22.2 No.62368-1
ETSI 300019-1-3, Class 3.2
IngressProtection: IEC 60529 IP20
Storage ETSI EN300 019-1-1 Class 1.2, ETSI EN 300 019-2-1 Specification T 1.2
Transportation ETSI EN300 019-1-2 Class 2.3, ETSI EN 300 019-2-2 Specification T2.3

Mechanical Specifications

Dimensions 44 mmx 428 mm x 156 mm
(1.73 inx 16.85 in x 6.14 in)
3 kg (6.6lb)

Environmental

IDU -5C to+45C
RFU -33C to+55C
Humidity 0 to 95%,non-condensing

IDU Standard Input -48 VDC

IDU DC Input Range -40.5to -60 VDC, Dual-feed power support

ABOUT CAMBIUM NETWORKS

Cambium Networks enablesservice providers, enterprises, industrial organizations, and governments to deliver exceptional digital
experiences and device connectivitywith compelling economics. Our ONE Network platform simplifies management of Cambium
Networks’ wired and wirelessbroadband and network edge technologies. Our customers can focus more resources on managing
their business rather than thenetwork. We make connectivity that just works.
Downloads

Documentation & Resources

Download datasheets and technical documentation for the PTP 850GP.

Data Sheet

Download PDF →
