Cambium Networks ePMP 3000L Fixed Wireless Access Point
Outdoor campus, stadium, and transportation hub deployments requiring IP67-rated weatherproof Wi-Fi coverage.
Talk to a Pro
ePMP 3000L
- Specs: 2x2 MIMO support with peak throughput of 600
- The ePMP 3000L is the third generation access point (AP) that carries on the interference tolerance mechanisms with an emphasis on high-performance in low-density point to multipoint sectors.
Better pricing available. Our experts can help you secure the lowest rate on this model. Talk to an expert →
Request a Quote- Fast shipping — same-day processing before 4:15 pm PST
- Authorized Reseller — Serving customers 20+ years
- Call for Bulk Pricing
Sorry, this product is no longer available, please contact us for a replacement.
Click here to jump to more pricing!
Product Overview
Cambium Networks ePMP 3000L Fixed Wireless Access Point
The ePMP 3000L is the third generation access point (AP) that carries on the interference tolerance mechanisms with an emphasis on high-performance in low-density point to multipoint sectors.
ePMP
Ideal Applications
Outdoor campus, stadium, and transportation hub deployments requiring IP67-rated weatherproof Wi-Fi coverage. High-throughput ePMP sector deployments for rural broadband ISPs and enterprise outdoor distribution.
Product Images
2 photos
Technical Details
Hardware Specifications
Comprehensive technical data for the ePMP 3000L to ensure compatibility with your deployment.
Spectrum
Channel Spacing Configurableon 5 MHz increments
Frequency Range 5100–5980MHz (exact frequencies as allowed by local regulations)
Channel Width 20 | 40| 80 MHz
Interface
MAC (Media Access Cambiumproprietary
Physical Layer
100/1000BaseT,rate auto-negotiated
Ethernet Interfaced
29V CambiumPoE (included)
Supported
Protocols Used IPv4/IPV6,UDP, TCP, ICMP, SNMPv2c, HTTPS, STP, SSH, IGMP Snooping
Network HTTPS,SNMPv2c, SSH
Management
VLAN 802.1Qwith 802.1p priority
ARQYes
Nominal Receive Sensitivity (w/FEC)@ 20 MHz Channel MCS0 = -89 dBm to MCS8 (256 QAM-3/4) = -66 dBm (per chain)
Nominal Receive Sensitivity (w/FEC)@40 MHz Channel MCS0 = -87 dBm to MCS9 (256QAM-5/6) = -64 dBm (per chain)
Nominal Receive Sensitivity (w/FEC)@80 MHz Channel MCS0 = -84 dBm to MCS9 (256QAM-5/6) = -59 dBm (per chain)
Modulation Levels (Adaptive)MCS0 (BPSK) to MCS 9 (256QAM 5/6)
GPS SynchronizationMCS0 (BPSK) to MCS 9 (256QAM 5/6)
Quality of Service (QoS)3-level priority (voice, high, low) with packet classification by DSCP; COS; VLAN ID; IP & MAC address; broadcast, multicast, and station priority; MIR/CIR support
Antenna 90/120degree 2x2 sector antenna (C050900D021B)
Transmit Power 0 to +29dBm (combined, to regional EIRP limit) (1 dB interval) ePMP 3000L FSR Access Point
Physical
Sector Antenna 2x50 ohm,RP (reverse polarity) SMA
Also compatiblewith RF Elements TwistPort Adaptor for ePMP
GPS Antenna 1x50 ohm,RP (reverse polarity) SMA
Optionalexternal GPS Puck Antenna (N000900L030A)
Surge Suppression 1 jouleintegrated
30V GigabitSurge Suppressor (C000000L065A) recommended for optimal surge protection
Environmental IP67 andIP68 compliant
Temperature -22F to+140F (-30C to +60C)
Power 12W (upto 15W in extreme cold temperatures when heater activated)
Input Voltage 30V nominal(14V to 30V range)
Note that14V minimum must be maintained at radio connector under all conditions, including long cable lengths
Weight 0.5 kg(1.1 lb) without bracket
Dimensions 84 x 223x 32 mm (3.3 x 8.8 x 1.3 in) without brackets
Security
Encryption 128 bitAES (CCMP mode)
Certifications
CE EN 301893 V2.1.1 (5.4 GHz), EN 302 502 V2.1.1 (5.8 GHz)
ePMP3000L 5 GHz Access Point Radio FSR 5.1-5.98 GHz (ROW) (US cord)
C050911A221A ePMP3000L 5 GHz Access Point Radio FSR 5.1-5.98 GHz (ROW) (EU cord)
ABOUT CAMBIUM NETWORKS
Cambium Networks enablesservice providers, enterprises, industrial organizations, and governments to deliver exceptional digital
experiences and device connectivitywith compelling economics. Our ONE Network platform simplifies management of Cambium
Networks’ wired and wirelessbroadband and network edge technologies. Our customers can focus more resources on managing
their business rather than thenetwork. We make connectivity that just works.
Downloads
Documentation & Resources
Download datasheets and technical documentation for the ePMP 3000L.
Data Sheet
Download PDF →Need Help?
Talk to a Pro →Pricing Notes:
- Pricing and product availability subject to change without notice.
